Pin Diode MMIC Switches V-Band

Mi-Wave offers Pin Diode MMIC Switches such as SPST, SPDT, SP3T, SP4T, SP6T, SP8T, SP12T, or others in the 100MHz to 110GHz range.  These reflective switches combine low loss, high isolation performance with  TTL driver in a compact package. Various driver options are available in higher isolation versions up to 60 dB. These switches can also be supplied without drivers.

SPST

V-Band, 50 – 75 GHz, High-Speed Switch

911VF/385TTL, Isolation 30dB, Insertion Loss 3dB, Switch Speed 50ns

SPDT

V-Band, 50 – 75 GHz, High-Speed Switch

912VF/385TTL, Isolation 30dB, Insertion Loss 4.0 dB, Switch Speed 50ns

SP4T

V-Band, 50 – 75 GHz, High-Speed Switch

914VF-30/385TTL, Isolation 30dB, Insertion Loss 6.5dB, Switch Speed 30ns
